AirPlay

• iOS, iPadOS and macOS

• Screen mirroring and content sharing

• Extend macOS display

• Code and password security

Google Cast

• Android, Chrome OS and Google Chrome

• Screen mirroring and cast from apps with DRM

• Prompt security

Miracast

• Android and Windows

• Screen mirroring

• Wi-Fi Direct and Miracast over infrastructure

• Extend Windows 10 desktop

• Touchback and pen support

• Code security

Guest connectivity

• Wi-Fi Hotspot

• 2.4 and 5 GHz channel selection

• WPA2 security

• Access control (Device only, Internet only or Internet + LAN)

• This device is restricted to indoor use only when operating in the 5150‑5350 MHz frequency

Video output

• 1 x HDMI 2.0 port

• Up to 4K UHD (4096 x 2160) at 60 FPS

• HDMI-CEC

• VESA Display Power Management Signaling

Audio output

Up to 192 kHz via HDMI

Networking

• 1 x Gigabit LAN

• 802.11ac/b/g/n 2Tx2R Wi-Fi

• IPv6 addresses

• Proxy

• 802.1X security

USB

• 1 x USB 3.1 Gen1 Type‑A port

• 1 x USB 2.0 port

Performance

Up to 8 simultaneous on-screen connections

Automatic updates

Provides new features and security enhancements

Cloud Management

Manage all your devices over the Internet.
Go to cloud.airserver.com

Warranty

2 years parts and labor

Certifications

CE, FCC and RCM

Weight

165g

Dimensions

70 x 70 x 35mm / 2.75 x 2.75 x 1.38in

Power

• Input: AC 100-240V

• Output: DC 12V / 2A

• Idle: 5W

• Maximum: 12W

VESA mount

75mm / 100mm
